Medium Voltage Transformers

BBC / ITE Dry Type Transformer 1000KVA (AA) 1333KVA (FA) HV: 12470 60KV BIL LV: 216Y/125V 10KV BIL LV Amps 2673 (AA) 3563 (FA) 3ph 60hz Temp Rise: 150°C 5.32% Impedance @ 1000KVA Ser# 24-30437 Taps: 13094V 44.1A (AA) 58.8A (FA) 12782V 45.2A (AA) 60.2A (FA) 12470V 46.3A (AA) 61.7A (FA) 12158V 47.5A (AA) 63.3A (FA) 11847V 48.7A (AA) 65.0A (FA) NEMA 1 Ventilated Enclosure 91"H x 48"W x 78"D Reconditioned with 1 Year Warranty

Square D Power Cast II Cast Coil Dry Type Transformer 1000KVA (AA) / 1500KVA (FA) HV: 12470V Delta LV: 480Y/277 Volts (Wye) 3 Phase 60hz Impedance: 5.73% 80°C / 80°C Rise Avg./Max.Amb. 30/40°C HV Winding: Cu 95KV BIL LV Widing: Cu 30KV BIL Ser# 31273781-001-01-1 Seismic Certification Label OSHPD Special Certification Pre-approval OSP-0025-10 Anchorage Not Pre-approved Rigid Floor Mounted Seismic Performace Characteristics: Sds (G)=0.36 z/h=1.0 Ip=1.5 Model 98A Digital Temperature Controlloer Taps (AA/FA Amps): 13094V 44.1A/66.1A 12782V 45.2A/67.8A 12470V 46.3A/69.4A 12158V 47.5A/71.2A 11847V 48.7A/73.1A LV Amps: 1203A/1804A NEMA 1 Enclosure 9700lbs 100"H x 100"W x 54"D Reconditioned with 1 Year Warranty

Sola/Hevi-Duty 1000KVA H.V. 12470V BIL 95 LV. 575/332V BIL 10 3ph 60hz 6.5% Impedence @ 170°C 150°C Temp Rise Taps: 13094 12782 12470 12158 11847 11535 11223 Ser# GM-249752 NEMA 1 Enclosure 90"H x 108"W x 58"D 6550lbs Reconditioned with 1 Year Warranty

Tech-Tran Dry Type Transformer 1000KVA Class AA High Voltage: 2400 Volt Delta Low Voltage: 2400 Volt Delta 3ph 60hz 6.11% Impedence @ 135°C 115°C Rise Taps: 2520 Volt 229 Amps 2480 Volt 235 Amps 2400 Volt 241 Amps 2340 Volt 247 Amps 2280 Volt 253 Amps Ser# 28085-1 (#246) & 28085-2 (#247) NEMA 3R Enclosure 90"H x 72 1/2" W x 48"D 6600 lbs Reconditioned with 1 Year Warranty

Accurate Electronics Division Power Transformer Dry Type 1000KVA (AA) High Voltage: 2400 Volt Delta Low Voltage: 480 Volt Delta (1202.81 Amps) 3 Phase 60hz 5.8% Impedence 150°C Rise Taps: 2520 Volt 229.11 Amps 2480 Volt 234.70 Amps 2400 Volt 240.56 Amps 2340 Volt 246.73 Amps 2280 Volt 253.22 Amps Ser# T892359387 Cat# 24209 NEMA 1 Enclosure 82"H x 68"W x 46"D 5100 lbs Reconditioned with 1 Year Warranty

Westinghouse Dry Type Type ASL Power Center Transformer Class AA 1000KVA HV: 4160V LV: 380Y/219V Cu 3ph 60hz 150°C Rise KV BIL: 25HV / 10LV LV Amps: 1804A IMP: 5.8% Ser# WEP-87311 Taps: 4365V 132.3A 4260V 135.5A 4160V 138.8A 4055V 142.4A 3950V 146.2A 90.5"H x 80"W x 47"D Reconditioned 1 Year Warranty

Siemens 1500KVA HV: 13800 LV: 480Y/277V 1805A 3ph 60hz kV BIL: 60HV / 10LV Class: AA Temp Rise: 150°C Insulation System: 220°C Imp: 5.75% SER# 52958-02 Al Wound Taps: 14490V 59.8A 14145V 61.2A 13800V 62.8A 13455V 64.4A 13110V 66.1A Nema 1 Enclosure 90"H x 89"W x 48"D Reconditioned with 1 Year Warranty

International Transformer Corporation 1500/2000KVA H.V. 12470V BIL 95KV L.V. 480/277V BIL 10KV 3ph 60hz 6.05% Impedence @ 100°C 80°C Temp Rise Copper Winding Taps: 13093 12782 12470 12158 11846 Ser# E6611-0592 NEMA 1 Enclosure 90"H x 90"W x 58"D 11500lbs Reconditioned with 1 Year Warranty

ABB (ASEA BROWN BOVERI) Dry Type Transformer 1500KVA (AA) / 2000KVA (FA) HV: 12470Y/7200 LV: 2400V Delta LV Amps: 361A (AA) / 481A (FA) KV BIL: 60HV / 20LV 3ph 60hz 5.79% IMP Al Wound 150°C Temp. Rise Taps: 13094V 66A (AA) 88A (FA) 12782V 68A (AA) 90A (FA) 12470V 69A (AA) 93A (FA) 12158V 71A (AA) 95A (FA) 11847V 73A (AA) 97A (FA) Nema 1 Enclosure 90"H x 50"W x 90"D Reconditioned with 1 Year Warranty

Westinghouse 1500KVA (AA) / 2000KVA (FA) HV: 13800 LV: 480Y/277V 1804A (AA) / 2406A (FA) 3ph 60hz kV BIL: 60HV / 10LV Temp Rise: 80°C Imp: 7.78% SER# 24-34913201 Cu Wound Taps: 14490V 59.8A (AA) 79.7A (FA) 14145V 61.2A (AA) 81.6A (FA) 13800V 62.8A (AA) 83.7A (FA) 13455V 64.4A (AA) 85.8A (FA) 13110V 66.1A (AA) 88.1A (FA) 12765V 67.8A (AA) 90.5A (FA) 12420V 69.7A (AA) 93.0A (FA) Nema 1 Enclosure 91"H x 90"W x 67"D Reconditioned with 1 Year Warranty

Ge Industrial Systems Dry Type Transformer 1500KVA (AA) / 2000KVA (FA) HV: 13800V Delta LV: 480Y/277V LV Amp 1804 (AA) / 2406(FA) KV BIL: 95HV 30LV 115°C Temp Rise 5.68% Imp 3ph 60hz Cu Wound Serial# P107932-DS67170001 Taps: 14490V 59.8A (AA) 79.7A (FA) 14145V 61.2A (AA) 81.6A (FA) 13800V 62.8A (AA) 83.7A (FA) 13455V 64.4A (AA) 85.8A (FA) 13110V 66.1A (AA) 88.1A (FA) NEMA 1 Enclosure 92"H x 108"W x 66"D Reconditioned with 1 Year Warranty

Sorgel/Square D Insulated Dry Type Transformer 1500KVA (AA) / 2000KVA (FA) HV: 13800 62.7\A (AA) 83.6A (FA) 95KV BIIL LV: 480Y/277V 1803A (AA) 2404A (FA) 10KV BIL 3ph 60hz SER# 204153 IMP: 6.1% (AA) / 8.1% (FA) 220°C Ins. System for 115°C Rise Taps: 14490 14145 13800 13455 13110 NEMA 1 Enclosure 92"H x 68"W x 54"D Reconditioned with 1 Year Warranty

Square D Power Cast II Cast Coil Dry Type Transformer 1500/2250KVA (AA/FA) Primary: 13200 Delta Secondary: 480Y/277V 3 Phase 60hz Primary BIL: 95KV Secondary BIL: 30KV Sec: Amps: 1804/2706 Temp Rise: 80°C Primary/Secondary Conductor: Cu Ser# 25260069-001-01-1 5.88% Impedance Taps & Amps (AA/FA): 13860 Volt 62.5/93.7 Amps 13530 Volt 64.0/96.0 Amps 13200 Volt 65.6/98.4 Amps 12870 Volt 67.3/100.9 Amps 12540 Volt 69.1/103.6 Amps NEMA 1 Enclosure 98.5"H x 96"W x 54"D Pictures were taken when Unit Arrived; Transformer Stored Indoors Reconditioned with 1 Year Warranty

Square D/Sorgel 1500KVA HV: 12470V Delta 69.4A 60 KV BIL LV: 4160GY/2400V 208.0A 30 KV BIL PowerDry Aluminum Wound 150°C Ins. System Imp: 6.24% Ser# 034123-A1 Taps: 13094 12782 12470 12158 11847 NEMA 1 Enclosure 94"H x 108"W x 54"D 8590lbs Used Reconditioned with 1 year Warranty.

Federal Pacific Dry Type Transformer 1500KVA Primary: 13200 Delta Secondary: 480Y/277V 3ph 60hz Primary BIL: 60KV Secondary BIL: 10KV Sec: Amps: 1804 Primary/Secondary Cond: Al Ser# 56486 5.73% Impedance Taps & Amps: 13875V 62.4A 13542V 64.0A 13200V 65.6A 12877V 67.3A 12545V 69.0A NEMA 1 Enclosure 90"H x 54"W x 90"D (Transformer Coils Perpendicular to Nameplate Side HV is on Left hand side, LV is on Right Hand Side) Reconditioned with 1 Year Warranty

Federal Pacific Dry Type Transformer 1500KVA Primary: 13200 Delta Secondary: 480Y/277V 3ph 60hz Primary BIL: 60KV Secondary BIL: 10KV Sec: Amps: 1804 Primary/Secondary Cond: Al Ser# 56486 5.72% Impedance Taps & Amps: 13875V 62.4A 13542V 64.0A 13200V 65.6A 12877V 67.3A 12545V 69.0A NEMA 1 Enclosure 90"H x 54"W x 90"D (Transformer Coils Perpendicular to Nameplate Side HV is on Left hand side, LV is on Right Hand Side) Reconditioned with 1 Year Warranty

Sorgel Transformers (Square D Company) 1500KVA H.V. 13800V 62.8A KV BIL 60 LV. 480Y/277V 1804A KV BIL 10 3ph 60hz 5.8% Impedence 220°C Ins System for 150°C Rise Taps: 14490 14145 13800 13455 13110 Ser# 06443573 A NEMA 1 Enclosure 92"H x 85"W x 54"D Reconditioned with 1 Year Warranty

Cutler-Hammer Dry Type Transformer Manufactured by ABB 2000KVA/2360KVA/3147KVA AA/AA/FA HV: 13800 Volt 95kV BIL LV: 480Y/277 Volt 10kV BIL 3ph 60hz LV Amps: 2406A/2839A/3785A Imp: 6.49% 80°C/115°/115° Rise Copper (Cu) Wound SER# 24-36560-01 Taps: 14490V 79.7A (AA) 94.0A (AA) 125.4A (FA) 14145V 81.6A (AA) 96.3A (AA) 128.4A (FA) 13800V 83.7A (AA) 98.7A (AA) 131.7A (FA) 13455V 85.8A (AA) 101.3A (AA) 135.0A (FA) 13110V 88.1A (AA) 103.9A (AA) 138.6A (FA) NEMA 3R Enclosure 110"H x 108"W x 66"D Reconditioned with 1 Year Warranty

The Electric Service Co 2000/2666KVA (AA/FA) H.V. 12470V BIL 95KV L.V. 480/277V BIL 10KV 3ph 60hz 5.6% Impedence @ 135°C 220°C Insulation Rise Copper Winding Taps: 13094 88.2A (AA) 117.6A (FA) 12782 90.3A (AA) 120.4A (FA) 12470 92.6A (AA) 123.5A (FA) 12158 95.0A (AA) 126.6A (FA) 11847 97.5A (AA) 129.9A (FA) Ser# 65445 NEMA 3R Enclosure 90"H x 84"W x 54"D 12500lbs Reconditioned with 1 Year Warranty

Square D Dry Type Transformer 2000KVA (115°C Rise Self Cooled) 2666KVA (115°C Rise Forced Air) 13200 Delta - 480Y/277V 3ph 60hz HV Winding BIL: 60KV LV BIL: 10KV Ser# 198910-1 5.5% Impedance @ 2000KVA 7.3% Impedance @ 2666KVA 87.4/116.5 Amps @ 13200 Volts 2404/3204 Amps @ 480 Volts HV Taps (Amps @ 2666KVA): 13860V 13530V 13200V 12870V 12540V NEMA 1 Enclosure 92"H x 96 1/2"W x 54"D 11000 lbs Reconditioned with 1 Year Warranty
