Low Voltage Transformers

Please note that our available online inventory is only a sampling of our available in-stock inventory. If you cannot locate the product you need, please call us at 1-800-328-1842. Our sales team will be happy to find it for you.

1000/1180/1573KVA 13800-480Y/277V Cutler-Hammer Dry Type Transformer #218

Cutler-Hammer Dry Type Transformer Manufactured by ABB 1000KVA/1180KVA/1573KVA AA/AA/FA HV: 13800 Volt 95kV BIL LV: 480Y/277 Volt 10kV BIL 3ph 60hz LV Amps: 1203A/1419A/1892A Imp: 6.13% 80°C/115°/115° Rise Copper (Cu) Wound SER# 24-36560-05 Taps: 14490V 39.8A (AA) 47.0A (AA) 62.7A (FA)14145V 40.8A (AA) 48.2A (AA) 64.2A (FA)13800V 41.8A (AA) 49.4A (AA) 65.8A (FA)13455V 42.9A (AA) 50.6A (AA) 67.5A (FA)13110V 44.0A (AA) 52.0A (AA) 69.3A (FA) NEMA 3R Enclosure 110"H x 108"W x 66"D Reconditioned with 1 Year Warranty
SKU: MVDT #218

1200KVA 460-460Y/266V 3 Phase Dry Type Transformer #230

Accurate Electronics 1200KVA High Voltage: 460 Volt Low Voltage: 460Y/266 Volt 3ph 60hz 150°C Rise IMP: 6.8% HV Amps: 1506 Amps LV Amps: 1506 Amps SER# 1882357153 Taps: 480 Volt 1443 Amps 460 Volt 1506 Amps 437 Volt 1585 Amps NEMA 1 Enclosure 83"H x 65"W x 46"D Reconditioned with 1 Year Warranty
SKU: LVDT#230

1500KVA 13800-480Y/277V ABB Dry Type Transformer #194

ABB 1500KVA H.V. 13800V 62.8A KV BIL 60 LV. 480Y/277V 1804A KV BIL 10 Harmonic K Factor = 1.8 3ph 60hz 5.81% Impedence 150°C Temp Rise Conductor: Cu/Cu Taps: 14490 14145 13800 13455 13110 Ser# DS74803001 NEMA 1 Enclosure 91 1/2"H x 80"W x 54"D Reconditioned with 1 Year Warranty
SKU: MVDT #194

2000/2800KVA 12470-480Y/277V GE Cast Epoxy Resin Dry Type Transformer #236

GE Cast Epoxy Resin Dry Type Transformer 2000KVA (Continuous Self Cooled) / 2800KVA (Continuous Forced Air (FA)) HV: 12470 LV: 480Y/277V BIL: HV - 95KV ; LV - 10KV 3ph 60hz Imp: 6.07% @ 2000KVA LV: 100°C Rise HV: 80°C Rise Cu Wound SER# R 275978 A Taps & Amperage @ 2800KVA: 13090V 124A 12780V 126A 12470V 130A 12160V 133A 11850V 136A 3370 Amps @ 480 Volts (2800KVA) NEMA 1 Enclosure 100"H x 90"W x 58"D Transformer Enclosure Only Has Pull section on Right Side (28"W x 38"D) Reconditioned with 1 Year Warranty
SKU: MVDT #236

2500KVA 4160-480Y/277V GE Dry Type Transformer #239, 241

General Electric 2500KVA HV: 4160V 30KV BIL Al LV: 480Y/277V 10KV BIL Al 3ph 60hz Impedance/Serial# #239 - 5.59% - #R 27A225B #241 - 5.64% - #R 27A225D #243 - 5.57% - #R 27A225F Aluminum Wound Low Voltage Connections on Left Hand Side High Voltage Connections on Right Hand Side Taps: 4360 Volt 441 Amps 4260 Volt 452 Amps 4160 Volt 463 Amps 4055 Volt 475 Amps 3950 Volt 487 Amps LV Amps: 4010 Amps (at 3333KVA) 90"H x 82"W x 53"D Core & Coil Weight: 7750lbs Total Weight 8850lbs Reconditioned with 1 Year Warranty
SKU: MVDT #239, #241, #243

30KVA 380-208y/120 3ph Hevi-Duty Dry Type Transformer

Hevi-Duty Transformer Catalog# T1379H30S-5 High Voltage: 380 Delta Low Voltage: 208Y/120 3 Ph 50/60 HZ 6.2% imp 150°C Rise Weight: 350Lbs Type 1 Enclosure TR-2011-15991 Reconditioned with 1 Year Warranty
SKU: 30380D

750/1000KVA 13800-480V National Industri Dry Type Transformer #268

National Industri Dry Type Transformer 750/1000KVA AA/FA Primary Voltage: 13800 Volt 95kV BIL Secondary Voltage: 480 Volt 30kV BIL 3ph 60hz Imp: 5.82% @ 135°C 115° C Rise 165°C Ins Sys Aluminum (Al) Wound SER# 01296-1 Manufacture Date: 02/87 Taps: 14490 14145 13800 13455 13110 NEMA 3R Enclosure 89"H x 84"W x 54"D Reconditioned with 1 Year Warranty
SKU: MVDT #268

AAA 50KVA 480-460/266 3PH Dry Type Transformer

AAA Dry Type Transformer CAT#UR050H2400T3 50KVA 480-460/266 3PH Type 1 Enclosure Loc: 15O2 Reconditioned with 1 Year Warranty
SKU: TR-2011-16558

AAA 75KVA 208-208/120V 3PH Dry Type Transformer

AAA Dry Type Transformer CAT#IC075B0500T3 75KVA 208-208/120V 3PH Type 1 Enclosure Loc: 8G2 Reconditioned with 1 Year Warranty
SKU: TR-2016-24617

ACME 112.5KVA 480-208Y/120V 3PH Dry Type Transformer

ACME Dry Type Transformer CAT#T-1A-53315-3S 112.5KVA 480-208Y/120V 3PH Type 1 Enclosure Loc: 15I1 Reconditioned with 1 Year Warranty
SKU: TR-2013-19537

ACME 118KVA 460-460Y/266V 3PH Dry Type Transformer

ACME Dry Type Transformer CAT#DTGB-0118-4S 118KVA 460-460Y/266V 3PH Type 1 Enclosure Loc: 10W2 Reconditioned with 1 Year Warranty
SKU: TR-2013-19343

ACME 14KVA 460-460/266V 3PH Dry Type Transformer

ACME Dry Type Transformer CAT#DTGB-014-23 14KVA 460-460/266V 3PH Type 1 Enclosure Loc: 11J2 Reconditioned with 1 Year Warranty
SKU: TR-2014-22581

ACME 15KVA 440-220Y/127V 3PH Dry Type Transformer

ACME Dry Type Transformer CAT#TF-22015-5S 15KVA 440-220Y/127V 3PH Type 1 Enclosure Loc: 11D2 Reconditioned with 1 Year Warranty
SKU: TR-2017-25065

ACME 225KVA 480-208/120 3PH Dry Type Transformer

ACME Dry Type Transformer CAT#ME-1-53317-1S 225KVA 480-208/120 3PH Type 1 Enclosure Loc: 15N1 Reconditioned with 1 Year Warranty
SKU: TR-2011-16579

ACME 225KVA 480-208/120 3PH Dry Type Transformer

ACME Dry Type Transformer CAT#ME-1-53317-1S 225KVA 480-208/120 3PH Type 1 Enclosure Loc: 12Q2 Reconditioned with 1 Year Warranty
SKU: TR-2011-16384

ACME 225KVA 480-208/120 3PH Dry Type Transformer

ACME Dry Type Transformer CAT#ME-1-53317-1S 225KVA 480-208/120 3PH Type 1 Enclosure Loc: 10R1 Reconditioned with 1 Year Warranty
SKU: TR-2011-16210

ACME 225KVA 480-208/120 3PH Dry Type Transformer

ACME Dry Type Transformer CAT#ME-1-53317-1S 225KVA 480-208/120 3PH Type 1 Enclosure Loc: 10Q1 Reconditioned with 1 Year Warranty
SKU: TR-2011-16209

ACME 37.5KVA 480-208/120 3PH Dry Type Transformer

ACME Dry Type Transformer CAT#T-1-53394-3 37.5KVA 480-208/120 3PH Type 1 Enclosure Loc: 14T2 Reconditioned with 1 Year Warranty
SKU: TR-2011-16510

ACME 7.5KVA 460-460Y/266V 3PH Dry Type Transformer

ACME Dry Type Transformer CAT#DTGB-7-2S 7.5KVA 460-460Y/266V 3PH Type 1 Enclosure Loc: 11F3 Reconditioned with 1 Year Warranty
SKU: TR-2016-24897

ACME 7.5KVA 460-460Y/266V 3PH Dry Type Transformer

ACME Dry Type Transformer CAT#DTGB-7-2S 7.5KVA 460-460Y/266V 3PH Type 1 Enclosure Loc: 11E2 Reconditioned with 1 Year Warranty
SKU: TR-2016-24895
