Eaton Pow-R-Line Switchboard MDS625 | 2500 Amp Main Breaker | 460V 3-Phase 3-Wire | NEMA 3R R&G

Product description:

Eaton Pow-R-Line Switchboard; 2500 amp main breaker- cat # MDS6253HEA, 460 volt, 3 phase, 3 wire, LSI functions, arc flash reduction, NEMA 3R outdoor. With (2) sections of C-Series breaker distribution panels. Reconditioned & guaranteed with a one-year warranty.

3 Sections: From Left to Right

Main Breaker Panel

• Eaton Power Xpert Meter
• 2500 Amp Frame Magnum DS Main Breaker
  • MDS625
  • Cat # MDS6253HEA 251CN MNNNE NNNAX
  • 3 Pole
    • Digitrip 1150+ Trip Unit
      • Cat # 11ARMLSI
      • LSI Functions
      • Arc Flash Reduction
      • No Ground Fault

Distribution 1 Panel

• (2) 800 Amp Breaker
  • Cat # HMDL3800F
  • 700 Amp Trip
    • Cat # MT3700T
• (2) 600 Amp Breaker
  • Cat # HLD3600F
  • 600 Amp Trip
    • Cat # LT3600T
• (1) 600 Amp Breaker
  • Cat # LGH3630NN
• (2) 15 Amp Breaker
  • HFD 65k

Distribution 2 Panel

• 400 Amp Breaker
  • Cat # HKD3400F
  • 400 Amp Trip
    • Cat # KT3400T
• HFD Breakers
  • (1) 150 Amp
  • (3) 125 Amp
  • (2) 50 Amp
  • (6) 30 Amp
  • (1) 25 Amp

Dimensions:

• Main Breaker Panel
  • 36" Width
  • 45" Depth
  • 90" Height

• Distribution 1 Panel
  • 36" Width
  • 45" Depth
  • 90" Height

• Distribution 2 Panel
  • 45" Width
  • 45" Depth
  • 90" Height
