Square D QED Power Style Switchboard 3000 Amp Fusible Main 480Y/277 Volt 3 Ph 4 W NEMA 1 R&G

Product description:

Square D QED Power Style Switchboard; 3000 amp fusible main, 480Y/277 volt, 3 phase, 4 wire, ground fault, NEMA 1 indoor rated. With 3 sections of fusible distribution sections. Reconditioned & guaranteed with a one year warranty.

4 Sections: From Right to Left

Main Fusible Panel

• Power Logic Circuit Monitor
• 3000 Amp Main Fusible Bolt-Loc Switch
  • Cat # BP03630EI
  • 480 Volt
• Ground Fault

Fusible Distribution 1 Panel

• 1200 Amp Fusible Switch
  • Cat # BPO3612EI
  • 480 Volt
• 1200 Amp Fusible Switch
  • Cat # BPO3612E
  • 480 Volt
• Ground Fault

Fusible Distribution 2 Panel

• 600 Amp Fusible Switch
  • Cat # QMB-366W
  • 480 Volt

Fusible Distribution 3 Panel

• 1200 Amp Fusible Switch
  • Cat # BPO3612E
  • 480 Volt
• Ground Fault

Dimensions:

• Main Panel
  • 42" Width
  • 36" Depth
  • 91" Height

• Distrubution Sections 1-3
  • 36" Width
  • 36" Depth
  • 91" Depth

M-678                      LOC: Pillar 118
