Square D QED Power Style Switchboard NW30H | 3000 Amp Main Breaker | 480Y/277V 3-Phase 4-Wire | NEMA 1 R&G

Product description:

Square D QED Power Style Switchboard; 3000 amp main breaker- cat # WL3HHG44A3SXXXXXXA, 480Y/277 volt, 3 phase, 4 wire, LSIG functions, ground fault, NEMA 1 indoor rated. With (3) sections of I-line breaker distribution panel. Reconditioned & guaranteed with a one-year warranty.

4 Sections: From Right to Left

Main Breaker Panel

• PowerLogic PM800
• 3000 Amp MasterPact Breaker
  • NW 30 H
  • Cat # WL3HHG44A3SXXXXXXA
  • Micrologic 6.0 A
    • LSIG functions
    • Ground Fault

I-Line Distribution 1 Panel

• (1) 1200 Amp PowerPact Breaker
  • Cat # PKA36120U44AE1
• (2) 800 Amp PowerPact Breaker
  • Cat # PKA36080CU44CE1SA
• (1) 600 Amp PowerPact Breaker
  • Cat # PKA36060CU44CE1SA
• (1) 400 Amp PowerPact Breaker
  • Cat # LJA36400CU44XENYH2
• (1) 400 Amp PowerPact Breaker
  • Cat # PKA36040CU44AR1

I-Line Distribution 2 Panel

• (2) 800 Amp PowerPact Breaker
  • Cat # PKA36080CU44AE1SA
• (2) 400 Amp PowerPact Breaker
  • Cat # PKA36040CU44AE1SA

I-Line Distribution 3 Panel

• (7) 400 Amp PowerPact Breaker
  • Cat # LJA36400CU44XENYH2
• (1) 250 Amp PowerPact Breaker
  • Cat # JJA36250U44XENYH2

Dimensions:

• Main Panel
  • 42" Width
  • 36" Depth
  • 91" Height
• Distribution 1 Panel
  • 42" Width
  • 36" Depth
  • 91" Height
• Distribution 2 Panel
  • 42" Width
  • 36" Depth
  • 91" Height
• Distribution 3 Panel
  • 42" Width
  • 36" Depth
  • 91" Height

M-703                      LOC: Pillar 114
