Square D QED Power Style Switchboard BPO3630 | 3000 Amp Fusible Main | 208Y/120V 3-Phase 4-Wire | NEMA 1 R&G

Product description:

Square D QED Power Style Switchboard; 3000 amp fusible main switch- cat # BPO3630, 208Y/120 volt, 3 phase, 4 wire, NEMA 1 indoor rated. With (2) sections of fusible distribution panels. Reconditioned & guaranteed with a one-year warranty.

3 Sections: From Left to Right

Main Panel

• Bolt-Loc bolted pressure contact switch
  • 3000 amps
  • 240 volts
  • Cat# BPO3630
  • 60 Hz
• PowerLogic Power Meter

Distribution 1 Panel

• (1) 1200 Amp
  • BPO3612I
  • 240 Volt AC

• (1) 1200 Amp
  • BPO3612
  • 240 Volt

Distribution 2 Panel

• (4) 400 Amp
  • QMB325W
  • 3 Pole
  • 240 Volt AC

• (1) 200 Amp
  • QMB324W
  • 3 Pole
  • 240 Volt AC

 Dimensions:

Main Panel

• 42" Width
• 36" Depth
• 91" Height

Distribution 1 Panel

• 36" Width
• 36" Depth
• 91" Height

 Distribution 2 Panel

• 36" Width
• 36" Depth
• 91" Height

M-623                   LOC: AB6 (Across from AB8)
