Square D QED Power Style Switchboard 2500 Amp Fusible Main 208Y/120 Volt NEMA 3R R&G

Product description:

Square D QED Power Style Switchboard; 2500 amp fusible main, 208Y/120 volt, 3 phase, 4 wire, NEMA 3R outdoor rated. With 2 sections of fusible distribution. Reconditioned & guaranteed with a one year warranty.

3 Sections: From Left to Right

Fusible Main Panel

• 2500 Amp Fusible Main Switch
• 208Y/120 Volt
• 3 Phase
• 4 Wire
• NEMA 3R

Fusible Distribution 1 Panel

• (1) 1200 Amp
  • Cat # QMB368W
• (1) 200 Amp
  • Cat # QMJ364H
• (10) 100 Amp
  • Cat # QMJ363T
• (2) 60 Amp
  • Cat # QMB362TW
• (2) 30 Amp
  • Cat # QMJ361T

Fusible Distribution 2 Panel

• (1) 1200 Amp
  • Cat # QMB368W
• (1) 200 Amp
  • Cat # QMB364W
• (4) 100 Amp
  • Cat # QMJ363T
• (4) 60 Amps
  • Cat # QMJ362T
• (6) 30 Amps
  • Cat # QMJ361T

Dimensions:

• Main Panel
  • 48" Width
  • 50" Depth
  • 92" Height

• Fusible 1 Dist Panel
  • 48" Width
  • 50" Depth
  • 92" Height

• Fusible 2 Dist Panel
  • 48" Width
  • 50" Depth
  • 92" Height
