Square D Power Style Switchboard 2500A Main Breaker 480Y/277V AC W/ LSIG NEMA 3R R&G

Product description:

Square D Power Style Switchboard:

  • 2500 amp main breaker
  • 480Y/277 volt AC
  • three phase
  • four wire
  • LSIG functions
  • Ground fault interrupter
  • Rating plug
    • cat# RP100
  • NEMA 3R outdoor

Pull section & breaker distribution sections

  • (5) MEF36400LIG
    • 400 Amp
    • 480 Volt AC
    • LIG Functions
    • 400 Amp Sensor (Frame)
    • Rating Plug
      • Cat# RP100
  • (2) MEF36600LSG
    • 600 Amp
    • 480 Volt AC
    • LSIG functions
    • 800 Amp Sensor (Frame)
    • Rating Plug
      • Cat# RP075
  • (1) MEF36800LIG
    • 800 Amp
    • 480 Volt
    • LIG functions
    • Rating Plug
      • Cat# RP100

Dimensions: From Left to Right

  • Pull Section
    • 24" Length
    • 75" Depth
    • 91" Height
  • Main
    • 42" Length
    • 75" Depth
    • 91" Height
  • Distribution 1
    • 24" Length
    • 75" Depth
    • 91" Height
  • Distribution 2
    • 24" Length
    • 75" Depth
    • 91" Height

Reconditioned & guaranteed with a 1 year warranty

M-459      LOC: Pillar 156

Specs:

  • Manufacturer : Square D
  • Amperage : 2500
  • Voltage : 480Y/277
  • Style : Breaker
  • Main Type : Circuit Breaker
  • Indoor/Outdoor : Outdoor
  • Ground Fault : Yes
  • Condition : Refurbished
  • Phase : 3
  • Wire : 4
Brand: Square D
SKU: M459
Contact us for pricing:
1-800-328-1842
