Square D Power-Style Switchboard 2000 Amp Main Lug Only 480 Volt 3 Ph 3W NEMA 1 R&G

Square D Power-Style Switchboard; 2000 amp main lug only, 480 volt AC, 3 phase, 3 wire, NEMA 1 indoor rated. With 1200 amp RL distribution breakers & I-Line distribution. Reconditioned & guaranteed with a one-year warranty.

3 Sections: From Left to Right

MLO Section:

• PowerLogic circuit monitor

Distribution 1 Section

• (1) 1200 Amp PowerPact Breaker
  • RL 1200
  • Cat# RLF36120CU44AE1ACBD
  • 480 Volt
  • Micrologic 6.0 A
  • LSIG Functions
• (1) RLA36120CU44
  • 1200 Amp
  • LSIG Functions
• (1) PLA34060CU44
  • 600 Amp
  • LSIG Functions
• (1) HLA36100
  • 100 Amp
• (2) HLA36080
  • 80 Amp
• (2) HLA36070
  • 70 Amp

Distribution 2 Section

• (1) PLA34060CU41AE1
  • 600 Amp
  • Micrologic 3.0 Functions
• (1) PLA34060CU41CE1
  • 600 Amp
  • Micrologic 3.0 Functions
• (1) LXI36300
  • 300 Amp
  • LSI Functions
• (2) KI36125
  • 125 Amp
• (2) HLA36090
  • 90 Amp
• (1) HJA36060
  • 60 Amp
• (1) HLA36040
  • 40 Amp
• (1) HLA36025
  • 25 Amp
• (1) HLA36020
  • 20 Amp
• (2) HLA260202
  • 20 Amp
• (3) HLA36015
  • 15 Amp

Dimensions:

• MLO Panel

  • 24" Width
  • 36" Depth
  • 91" Height

• Distribution 1 Panel

  • 48" Width
  • 36" Depth
  • 91" Height

• Distribution 2 Panel
  • 42" Width
  • 36" Depth
  • 91" Height

M-682                   LOC: Pillar 135  (SPR-D9)
