SQ D Power Style Switchboard BP032300 Fusible 3000 Amp 240 Volt AC NEMA 1 R&G

Product description:

Square D Power Style Switchboard BP032300 fusible; 3000 amp fusible main, 240 volt AC, three pole, NEMA 1 indoor, with I-line distribution. Reconditioned & guaranteed with a one year warranty.

Fusible Main

• MFG# BP032300
• 3000 Amp
• 240 Volt AC
• 3 Phase
• 3 Wire
• NEMA 1 Indoor

I-Line Distribution Sections (2)

• (1) FA34100
  • 100 Amp
  • 480 Volt AC
  • 250 Volt DC
  • Series 2
• (3) KA36225
  • 225 Amp
  • 600 Volt AC
  • Seies 2
• (3) LA36400
  • 400 Amp
  • 600 Volt AC
  • Series 4
  • Magnetic Trip Range
    • LO- 2000 Amp
    • HI- 4000 Amp
• (2) MA36600
  • 600 Amp
  • 600 Volt AC
  • Series 2
  • Magnetic Trip Range
    • LO- 3000 Amp
    • HI- 6000 Amp
• (2) MA36800
  • 800 Amp
  • 600 Volt AC
  • Series 2
  • Magnetic Trip Range
    • LO- 4000 Amp
    • HI- 8000 Amp
• (1) NA361000
  • 1000 Amp
  • 600 Volt AC
  • Series 1

Dimensions: Right to Left

• Main Section
  • 42" Width
  • 40" Depth
  • 90" Height

• Distribution (1)
  • 36" Width
  • 36" Depth
  • 90" Height

• Distribution (2)
  • 48" Width
  • 36" Depth
  • 90" Height

(M-489      LOC: Pillar 124)
