Siemens 1600 Amp QA-1633 Pringle Main Switchboard 208Y/120 Volt 3 Phase 4 Wire NEMA 1 R&G

Product description:

Siemens Pringle Main Fusible Switchboard; cat# QA-1633, 1600 amp, 208/120 volt, 3 phase, 4 wire, NEMA 1 indoor. With ITE Vacu-Break switch distribution sections. Reconditioned & guaranteed with a one-year warranty.

3 Sections:

Fusible Main Panel

• Type FC I
• Series 6
• Pringle Main Fusible Switch
  • 1600 Amps
  • 480 Volts
  • 60Hz
  • Cat# QA-1633
  • Serial# C52046S
  • DWG# M-49499
• Metering

Fusible ITE Vacu-Break Switches Distribution Panel 1

• (3) 400 Amps
  • Cat# V7H3205
  • 240 Volts
  • 3 Poles
  • 3 Phase

• (1) 600 Amps
  • Cat# V7H3206
  • 240 Volts
  • 3 Poles
  • 3 Phase

Fusible ITE Vacu-Break Distribution Panel 2

• (1) 100 Amps
  • Cat# V7E3203
  • 240 Volts
  • 3 Poles
  • 3 Phase

• (1) 200 Amps
  • Cat# V7F3204
  • 240 Volts
  • 3 Poles
  • 3 Phase

Dimensions: From Left to Right

Main Fusible Panel

• 38" Width
• 28" Depth
• 90" Height

Fusible Distribution Panel 1

• 38" Width
• 28" Depth
• 90" Height

Fusible Distribution Panel 2

• 32" Width
• 28" Depth
• 90" Height

M-542               LOC: Air Breaker Aisle
