General Electric Spectra Switchboard | 4000 Amp Main Lug Only | 208Y/120V 3-Phase 4-Wire | NEMA 1 R&G

Product description:

General Electric Spectra Switchboard; 4000 amp main lug only, 208Y/120 volt, 3 phase, 4 wire, NEMA 1 indoor. With (1) 1600 amp Power Break distribution panel & (2) spectra series breaker distribution. Reconditioned & guaranteed with a one-year warranty.

4 Sections: From Right to Left

Pull Panel

Distribution 1 Panel

• (1) 1200 Amp
  • Cat # TKL4V4612
  • 1200 Amp MicroVersa Trip Unit
    • Instantaneous
• (1) 800 Amp
  • Cat # SKLA36AT0800
  • Rating Plug- # SRPG600A350
• (1) 400 Amp
  • Cat # SGHA36AT0400
  • Rating Plug- # SRPG400A400
• (1) 400 Amp
  • Cat # SGHA36AT0400
  • Rating Plug- # SRPG400A350
• 250 Amp
  • Cat # SFHA36AT0250
  • Rating Plug- # SRPF250A175

Distribution 2 Panel

• (1) 1600 Amp Power Break
  • Cat # TP1616TTR
  • MicroVersa Trip Plus Trip Unit
    • Cat # C216LI
  • 1600 Amp Rating Plug
    • Cat # TR16B1600

Distribution Spectra RMS 3 Panel

• (1) 600 Amp
  • Cat # SGLA36AT0600
  • Rating Plug- # SRPK600A600
• (2) 400 Amp
  • Cat # SGHA36AT0400
  • Rating Plug- # SRPG400A250
• (1) 400 Amp
  • Cat # SGHA36AT0400
  • Rating Plug- # SRPG400A225
• (1) 250 Amp
  • Cat # SFHA36AT0250
  • Rating Plug- # SRPF250A200
• (1) 250 Amp
  • Cat # SFHA36AT0250
  • Rating Plug- # SRPF250A175
• (2) 250 Amp
  • Cat # SFHA36AT0250
  • Rating Plug- # SRPF250A150
• (2) 250 Amp
  • Cat # SFHA36AT0250
  • Rating Plug- # SRPF250A125
• (1) THED136100
• (1) THED136060
• (1) THED136050
• (1) THED136030

Dimensions:

• Pull Panel
  • 35" Width
  • 35" Depth
  • 90" Height

• Distribution 1 Panel
  • 45" Width
  • 35" Depth
  • 90" Height

• Distribution 2 Panel
  • 30" Width
  • 35" Depth
  • 90" Height

• Distribution 3 Panel
  • 45" Width
  • 35" Depth
  • 90" Height
