General Electric Main-Tie Spectra Series Switchboard 1600 Amp Main Breaker 480Y/277 Volt 3 Ph 4 W NEMA 1 R&G

Product description:

General Electric Spectra Series Switchboard Main-Tie; 1600 amp main breaker, 480Y/277 volt, 3 phase, 4 wire, LSIG functions, ground fault, NEMA 1 indoor rated. With (1) Tie section, & (1) spectra breaker distribution section. Reconditioned & guaranteed with a one-year warranty.

3 Sections: From Right to Left

Main Panel

• (2) PQM II Power Quality Meter
• 1600 Amp Power Break II Main Breaker
  • Cat # SSF16G216
  • Shunt Trip
    • 120 VAC, 50/60 Hz, 125 VDC
    • Cat # SPST120
  • Bell Alarm/ Lock Out
    • Cat # SPBAL240
  • 1600 Amp EntelliGuard TU Trip Unit
    • Cat # GB216L4XXXFXXXX
    • LSIG Functions
  • 1600 Amp Rating Plug
    • Cat # GTP1600U1640

Tie Panel

• 1600 Amp Power Break II Tie Breaker
  • Cat # SSF16G216
  • Shunt Trip
    • 120 VAC, 50/60 Hz, 125 VDC
    • Cat # SPST120
  • Bell Alarm/ Lock Out
    • Cat # SPBAL240
  • 1600 Amp EntelliGuard TU Trip Unit
    • Cat # GB216L4XXXFXXXX
    • LSIG Functions
  • 1600 Amp Rating Plug
    • Cat # GTP1600U1640

Spectra Breaker Distribution Panel

Dimensions:

• Main Panel
  • 30" Width
  • 30" Depth
  • 90" Height
• Tie Panel
  • 30" Width
  • 30" Depth
  • 90" Height
• Dist Panel
  • 35" Width
  • 30" Depth
  • 90" Height
