General Electric AV-Line Switchboard THP3030SS | 3000 Amp Main Breaker | 208Y/120V 3-Phase 4-Wire | NEMA 1 R&G

Product description:

General Electric AV-Line Switchboard; 3000 amp main breaker- cat # THP3030SS, 208Y/120 volt, 3 phase, 4 wire, ground fault, NEMA 1 indoor. With (2) sections of Spectra breaker distribution panels. Reconditioned & guaranteed with a one-year warranty.

3 Sections: From Right to Left

Main Breaker Panel

• 3000 Amp Power Break Main Breaker
  • Cat # THP3030SS
  • RMS-9 MicroVersaTrip
    • Cat # S32LIGT2
    • LIG Functions
    • Ground Fault
  • 3000 Amp Rating Plug
    • Cat # TR30S3000

Spectra Breaker Distribution 1 Panel

• (1) 600 Amp Spectra Breaker
  • Cat # TJL6S
  • RMS-9 MicroVersaTrip
    • Cat # TS20LIGT2
    • LIG Functions
  • 600 Amp Rating Plug
    • Cat # TR6S600J
• (1) 400 Amp Spectra Breaker
  • Cat # TJL4S
  • RMS-9 MicroVersaTrip
    • Cat # TS20LIGT2
    • LIG Functions
  • 400 Amp Rating Plug
    • Cat # TR4S400J
• (1) 150 Amp Spectra Breaker
  • Cat # TJL1S
  • MicroVersaTrip Trip Unit
    • Cat # C201LIG
    • LIG Functions
  • 100 Amp Rating Plug
    • Cat # TR1B100

Power Break Distribution 2 Panel

• 2000 Amp Breaker
  • Cat # THP2020SS

Dimensions:

• Main Panel
  • 40" Width
  • 36" Depth
  • 90" Height

• Dist 1 Panel
  • 40" Width
  • 36" Depth
  • 90" Height

• Dist 2 Panel
  • 40" Width
  • 36" Depth
  • 90" Height

M-737                              LOC: Across from SPR-B16
