GE AV-Line Switchboard 3000A 480Y/277V QA-3033-CBC Main-Tie-Main NEMA 1 GFI R&G

Product description:

GE AV-Line Switchboard Main-Tie-Main; 3000 amp, 480Y/277 volt, three phase, four wire. (2) QA-3033-CBC fusible main switch with ground fault, fusible distribution, Nema 1 indoor rated, reconditioned and guaranteed with a one year warranty.

9 Sections

(2) Fusible Main Sections

• Fusible Pringle Main
  • Cat# QA-3033-CBC
  • Serial# F-06688 & F-06687
  • 3000 Amp
  • 480 Volt
  • 60 Hz
  • Three Phase
  • Four Wire
  • Dwg# M-55400
  • Ground Fault

• Fusible Distribution Sections (7)
  • (5) QA-0833-B
    • 800 Amp
    • 480 Volt
  • (3) QA-0833
    • 800 Amp
    • 480 Volt
  • (1) QA-0833-CBC
    • 800 Amp
    • 480 Volt
  • (1) QA-1233
    • 1200 Amp
    • 480 Volt

Dimensions: 9 Sections From Left to Right

• Main 1
  • 60" Width
  • 40" Depth
  • 90" Height
• Tie 1
  • 30" Width
  • 40" Depth
  • 90" Height
• Tie 2
  • 30" Width
  • 40" Depth
  • 90" Height
• Tie 3
  • 30" Width
  • 40" Depth
  • 90" Height
• Tie 4
  • 45" Width
  • 40" Depth
  • 90" Height
• Tie 5
  • 30" Width
  • 40" Depth
  • 90" Height
• Tie 6
  • 30" Width
  • 40" Depth
  • 90" Height
• Tie 7
  • 30" Width
  • 40" Depth
  • 90" Height
• Main 2
  • 60" Width
  • 40" Depth
  • 90" Height

NEMA 1 Indoor

Reconditioned & Guaranteed with a one year warranty

M-478      LOC: Pillar 128
