Eaton Pow-R-Line Xpert Switchboard 2000 Amp Breaker Main 480 Volt 3 Ph 3 W NEMA 1 R&G

Product description:

Eaton Pow-R-Line Xpert Switchboard; 2000 amp breaker main, 480 volt, 3 phase, 3 wire, LSIG functions, ground fault, NEMA 1 indoor rated. With breaker distribution panel. Reconditioned & guaranteed with a one-year warranty.

2 Sections: From Left to Right

Main Breaker Panel

• Eaton SPD Series Surge Protective Device
• 2000 Amp Magnum SB Main Breaker
  • SBS620
  • Cat # SBS6203HEA 201GN MNN4E NNNFX
  • Digitrip 1150+ Trip Unit
    • Cat # 11ARMLSIG
    • Ground Fault
  • Accessories
    • Trip Unit Power
      • 120 VAC
      • 50/60 Hz
    • Auxiliary Switch
      • 4A/4B

Breaker Distribution Panel

• Eaton PDG Breakers
  • (2) 800 Amp
  • (3) 400 Amp
  • (1) 125 Amp
  • (5) 100 Amp

Dimensions

• Main Panel
  • 36" Width
  • 30" Depth
  • 90" Height

• Distribution Panel
  • 36" Width
  • 30" Depth
  • 90" Height

M-712              LOC: Pillar 137 (A-8)
