1000KVA 2400-2400V 3ph Tech Tran Dry Type Transformer (#246 & 247)

Tech-Tran Dry Type Transformer 1000KVA Class AA High Voltage: 2400 Volt Delta Low Voltage: 2400 Volt Delta 3ph 60hz 6.11% Impedence @ 135°C 115°C Rise Taps: 2520 Volt 229 Amps 2480 Volt 235 Amps 2400 Volt 241 Amps 2340 Volt 247 Amps 2280 Volt 253 Amps Ser# 28085-1 (#246) & 28085-2 (#247) NEMA 3R Enclosure 90"H x 72 1/2" W x 48"D 6600 lbs Reconditioned with 1 Year Warranty
SKU: MVDT #246 #247

1000KVA 2400-480V 3ph Accurate Electronics Division Dry Type Transformer #288

Accurate Electronics Division Power Transformer Dry Type 1000KVA (AA) High Voltage: 2400 Volt Delta Low Voltage: 480 Volt Delta (1202.81 Amps) 3 Phase 60hz 5.8% Impedence 150°C Rise Taps: 2520 Volt 229.11 Amps 2480 Volt 234.70 Amps 2400 Volt 240.56 Amps 2340 Volt 246.73 Amps 2280 Volt 253.22 Amps Ser# T892359387 Cat# 24209 NEMA 1 Enclosure 82"H x 68"W x 46"D 5100 lbs Reconditioned with 1 Year Warranty
SKU: MVDT #288

300KVA 2400-480V 3ph Southern Transformer Co Dry Type Transformer #206

Southern Transformer Company Dry Type Transformer 300KVA (AA/FA) High Voltage: 2400 Volt BIL 30KV Low Voltage: 480V BIL 10KV 3ph 60hz 4.19% Impedence @ 75°C 150°C Rise Taps: 2520 Volt 2480 Volt 2400 Volt 2340 Volt 2280 Volt Ser# T7886 NEMA 3R Enclosure 61"H x 63 1/2" W x 40 1/2"D 2650 lbs Reconditioned with 1 Year Warranty
SKU: MVDT #206
