ITE & Siemens

Please note that our available online inventory is only a sampling of our available in-stock inventory. If you cannot locate the product you need, please call us at 1-800-328-1842. Our sales team will be happy to find it for you.

15 HK ITE Gould 15KV 1200A EO/DO Power Circuit Breaker Used EMSCO# 19572

ITE Gould Type 15 HK Power circuit breaker; rated KV 13.8, maximum KV 15, impulse KV 95, frequency 60, rated continuous current: 1200 amp, rated Sym. MVA 11.5-15.0 KV - 500 rated Sym. short-circuit current - 19300 asymmetrical rating factor, 1.2 rated interr. time 5 cycles, control voltage: charge: 230-AC, close: 48-DC, Trip: 48-DC, model 03-B, used as-is.
SKU: 15HK # 19572

15 HK ITE Gould 15KV 1200A EO/DO Power Circuit Breaker Used EMSCO#19573

ITE Imperial Corporation Type 15 HK Power circuit breaker; rated KV 13.8, maximum KV 15, impulse KV 95, frequency 60, rated continuous current: 1200 amp, rated Sym. MVA 11.5-15.0 KV - 500 rated Sym. short-circuit current - 19300 asymmetrical rating factor 1.2 rated Interr. time 5 cycles, control voltage: charge: 115-AC close: 115-AC trip: 250-DC model, 03-B used as-is.
SKU: 15HK #19573

15 HK ITE Imperial 15KV 1200A EO/DO Power Circuit Breaker Used EMSCO# 19571

ITE Imperial Corporation Type 15 HK Power circuit breaker; rated KV 13.8, maximum KV 15, impulse KV 95, frequency 60, rated continuous current: 1200 amp, rated Sym. MVA 11.5-15.0 KV - 500 rated Sym. short-circuit current - 19300 asymmetrical rating factor 1.2 rated Interr. time 5 cycles, control voltage: charge: 115-AC, close: 115-AC trip: 250 DC, model 03-B, used as-is.
SKU: 15HK #19571

1500 13800-480Y/277V 3Ph Siemens Dry Type Transformer #270

Siemens 1500KVA HV: 13800 LV: 480Y/277V 1805A 3ph 60hz kV BIL: 60HV / 10LV Class: AA Temp Rise: 150°C Insulation System: 220°C Imp: 5.75% SER# 52958-02 Al Wound Taps: 14490V 59.8A 14145V 61.2A 13800V 62.8A 13455V 64.4A 13110V 66.1A Nema 1 Enclosure 90"H x 89"W x 48"D Reconditioned with 1 Year Warranty
SKU: MVDT #270

15-3AFR-500-37 Siemens Vacuum Conversion, 1200A, 15KV, EO/DO #22751

15-3AFR-500-37 Siemens Vacuum Conversion, 1200A, 15KV, EO/DO #22751 1200 Amps 15 KV Electrically Operated Draw Out Motor: 208-254 VAC Close: 208-254 VAC Trip: 28-56 VDC
SKU: 15-3AFR-500-37-#22751

15HK ITE 15KV 1200A EO/DO Circuit Breaker, Used, EMSCO #19581

ITE 15HK circuit breaker; 1200 amp, 15KV rated, three pole. Control: 125 volt DC, electrically operated / draw-out. Sold used as-is **** No label on unit.
SKU: 15HK - EMSCO #19581

15HK ITE 15KV 1200A EO/DO Circuit Breaker, Used, EMSCO #19582

ITE 15HK circuit breaker; 1200 amp, 15 KV rated, three pole. Control: 125 volt DC, electrically operated / draw-out. Sold used as-is.
SKU: 15HK - EMSCO #19582

2500/3333KVA 13800-480Y/277V Siemens Dry Type Cast Core Transformer #121

Siemens Ventilated Dry Type Transformer Cast Core & Coil 2500KVA (AA) / 3333KVA (Future FA) HV: 13800V 95KV BIL LV: 480Y/277V 10KV BIL LV Amps: 3008 (AA) / 4011A (FA) 3ph 60Hz 185°C Insulation System for 115°C Rise 5.94% Impedance @ 2500KVA Al Wound Cu Bussed Taps: 14490V 99.6A (AA) 133A (FA) 14145V 102A (AA) 136A (FA) 13800V 105A (AA) 139A (FA) 13155V 107A (AA) 143A (FA) 13110V 110A (AA) 147A (FA) Ser# 03005-1-1 NEMA 1 Enclosure 102"H x 109"W x 60"D Reconditioned with 1 Year Warranty
SKU: MVDT #121

2500/3333KVA 13800-480Y/277V Siemens Dry Type NEMA 3R Cast Core Transformer #123

Siemens Ventilated Dry Type Transformer Cast Core & Coil 2500KVA (AA) / 3333KVA (Future FA) HV: 13800V 95KV BIL LV: 480Y/277V 10KV BIL LV Amps: 3008 (AA) / 4011A (FA) 3ph 60Hz 185°C Insulation System for 115°C Rise 5.96% Impedance @ 2500KVA Al Wound Cu Bussing Taps: 14490V 99.6A (AA) 133A (FA) 14145V 102A (AA) 136A (FA) 13800V 105A (AA) 139A (FA) 13155V 107A (AA) 143A (FA) 13110V 110A (AA) 147A (FA) Ser# 02817-1 NEMA 3R Enclosure 102"H x 114"W x 71"D Reconditioned with 1 Year Warranty
SKU: MVDT #123

3000/4000KVA 13800-480D Siemens Dry Type Cast Core Transformer #125

Siemens Ventilated Dry Type Transformer Cast Core & Coil 3000KVA (AA) / 4000KVA (Future FA) HV: 13800V 95KV BIL LV: 480V 10KV BIL LV Amps: 3610A (AA) / 4813A (FA) 3ph 60Hz 185°C Insulation System for 115°C Rise 6.05% Impedance @ 3000KVA Al Wound Cu Bussing Taps: 14490V 120A (AA) 159A (FA) 14145V 122A (AA) 163A (FA) 13800V 126A (AA) 167A (FA) 13155V 129A (AA) 172A (FA) 13110V 132A (AA) 176A (FA) Ser# 03006-1-1 NEMA 1 Enclosure 104"H x 120"W x 60"D
SKU: MVDT #125

3400KVA 13800-700V Siemens Dry Type Transformer #175

Siemens Dry Type Transformer (Manufactured by Hammond MFG CO LTD) 3400KVA (AA) HV: 13800V 60KV BIL LV: 700V 2804A Suitable for Overload: 125% FOR 2HRS 175% FOR 60SEC 150°C Rise 220 Temp Class 3ph 60hz 5.28% IMP @ 170°C 3400KVA Al Windings Ser# DB94L Taps: 14490V 135.4A 14145V 138.7A 13800V 142.2A 13455V 145.8A 13110V 149.7A NEMA 1 Enclosure 102 1/2"H x 108"W x 58"D
SKU: MVDT #175

3400KVA 13800-700Y/404V Siemens Dry Type Transformer #176

Siemens Dry Type Transformer (Manufactured by Hammond MFG CO LTD) 3400KVA (AA) HV: 13800V 60KV BIL LV: 700Y/404V 2804A Suitable for Overload: 125% FOR 2HRS 175% FOR 60SEC 150°C Rise 220 Temp Class 3ph 60hz 5.55% IMP @ 170°C 3400KVA Al Windings Ser# DB94L Taps: 14490V 135.4A 14145V 138.7A 13800V 142.2A 13455V 145.8A 13110V 149.7A NEMA 1 Enclosure 102 1/2"H x 108"W x 58"D
SKU: MVDT #176

3WN Siemens 1250 Amp 690 VAC EO/STA Used E-OK MC-CB# 22713

Siemens 3WN5231-1GB56-1GA1 AG; 1250 amp, 690 VAC, 50/60Hz, electrically operated (EO), 110 volt AC / 48 volt DC, stationary/fixed mount (STA), used E-OK. MC-CB# 22713 Loc: S3B1
SKU: 3WN MC-CB#22713

3WN Siemens 1250 Amp 690 VAC EO/STA Used E-OK MC-CB# 22714

Siemens 3WN5231-1GB56-3GA1 AG; 1250 amp, 690 VAC, 50/60Hz, electrically operated (EO), 110 volt AC stationary/fixed mount (STA), used E-OK. MC-CB# 22714 Loc: S3A1
SKU: 3WN MC-CB#22714

3WN Siemens 1250 Amp 690 VAC EO/STA Used E-OK MC-CB# 22715

Siemens 3WN5231-1GB56-1GA1 AG; 1250 amp, 690 VAC, 50/60Hz, electrically operated (EO), 110 volt AC/48 volt DC, stationary/fixed mount (STA), used E-OK. MC-CB# 22715 Loc: S3A1
SKU: 3WN MC-CB#22715

3WN Siemens 1250 Amp 690 VAC EO/STA Used E-OK MC-CB# 22716

Siemens 3WN5231-1GB56-3GA1 AG; 1250 amp, 690 VAC, 50/60Hz, electrically operated (EO), 110 volt AC, stationary/ fixed mount (STA), used E-OK. MC-CB# 22716 Loc: S3A1
SKU: 3WN MC-CB#22716

3WN Siemens 1250 Amp 690 VAC EO/STA Used E-OK MC-CB# 22717

Siemens 3WN5231-1GB56-1GA1 AG; 1250 amp, 690 VAC, 50/60Hz, electrically operated (EO), 110 volt AC/48 volt DC, stationary/ fixed mount (STA), used E-OK. MC-CB# 22717 Loc: S3A1
SKU: 3WN MC-CB#22717

3WN Siemens 1250 Amp 690 VAC EO/STA Used E-OK MC-CB# 22723

Siemens 3WN5231-1GB56-1GA1 AG; 1250 amp, 690 VAC, 50/60Hz, electrically operated (EO), 110 volt AC/48 Volt DC, stationary/fixed mount (STA), used E-OK. MC-CB# 22723 Loc: S3B1
SKU: 3WN MC-CB#22723

3WN Siemens 1250 Amp 690 VAC EO/STA Used E-OK MC-CB# 22724

Siemens 3WN5231-1GB56-1GA1 AG; 1250 amp, 690 VAC, 50/60Hz, electrically operated (EO), 110 volt AC/48 volt DC, stationary/fixed mount (STA), used E-OK. MC-CB# 22724 Loc: S3B1
SKU: 3WN MC-CB#22724

3WN Siemens 1250 Amp 690 VAC EO/STA Used E-OK MC-CB# 22725

Siemens 3WN5231-1GB56-1GA1 AG; 1250 amp, 690 VAC, 50/60Hz, electrically operated (EO), 110 Volt AC/48 Volt DC, stationary/fixed mount (STA), used E-OK. MC-CB# 22725 Loc: S3A1
SKU: 3WN MC-CB#22725
